R18減速機詳細信息
R18減速機
訂購熱線：13360667204
R18減速機傳動比計算：齒輪減速馬達
輸送帶參數：輪子直徑50，負載0.5噸，一分鐘走50米
50米÷（0.05輪子直徑×3.14）=318.5轉每分鐘
0.5噸換算成N=5000N
5000×0.025輪子半徑×0.06摩擦系數=7.5N.m
通常確保萬無一失，我們會把輸出扭矩放大兩倍7.5×2=15N.m
電機轉數1400÷輸出轉數318.5=4.39比
15N.m輸出扭矩÷4.39比=3.41N.m電機扭矩
3.41N.m電機扭矩換算成功率0.55KW以上
對應的R18減速機選型參數：
型號：R18-B0.55KW
減速比：4.51
輸出轉數：306轉每分鐘
輸出扭矩：17N.m
安全系數：2.80
R18減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機
R18臥式硬齒面斜齒輪減速機型號：
R17FDM63L4,R17FDM63M4,R17FDM63MS4,R17FDM63S4,R17FDM71D4,R17FDM71M4,R17FDM71MS4,R17FDM71S4,R17FDM80K4,R17FDM80M4,R17FDM80MK4,R17FDM80N4,R17FDM80S4,R17FDR63L4,R17FDR63M4,R17FDR63MS4,R17FDR63S4,R17FDR71D4,R17FDR71M4,R17FDR71MS4,R17FDR71S4,R17FDR80K4,R17FDR80M4,R17FDR80MK4,R17FDR80N4,R17FDR80S4,R17FDRE63L4,R17FDRE63M4,R17FDRE63MS4,R17FDRE63S4,R17FDRE71D4,R17FDRE71M4,R17FDRE71MS4,R17FDRE71S4,R17FDRE80K4,R17FDRE80M4,R17FDRE80MK4,R17FDRE80N4,R17FDRE80S4,R17FDRN63L4,R17FDRN63M4,R17FDRN63MS4,R17FDRN63S4,R17FDRN71D4,R17FDRN71M4,R17FDRN71MS4,R17FDRN71S4,R17FDRN80K4,R17FDRN80M4,R17FDRN80MK4,R17FDRN80N4,R17FDRN80S4,R17FDRS63L4,R17FDRS63M4,R17FDRS63MS4,R17FDRS63S4,R17FDRS71D4,R17FDRS71M4,R17FDRS71MS4,R17FDRS71S4,R17FDRS80K4,R17FDRS80M4,R17FDRS80MK4,R17FDRS80N4,R17FDRS80S4,R17FDT63L4,R17FDT63M4,R17FDT63MS4,R17FDT63S4,R17FDT71D4,R17FDT71M4,R17FDT71MS4,R17FDT71S4,R17FDT80K4,R17FDT80M4,R17FDT80MK4,R17FDT80N4,R17FDT80S4,R17FDV63L4,R17FDV63M4,R17FDV63MS4,R17FDV63S4,R17FDV71D4,R17FDV71M4,R17FDV71MS4,R17FDV71S4,R17FDV80K4,R17FDV80M4,R17FDV80MK4,R17FDV80N4,R17FDV80S4,R17FDVE63L4,R17FDVE63M4,R17FDVE63MS4,R17FDVE63S4,R17FDVE71D4,R17FDVE71M4,R17FDVE71MS4,R17FDVE71S4,R17FDVE80K4,R17FDVE80M4,R17FDVE80MK4,R17FDVE80N4,R17FDVE80S4,R17F-Y0.12KW,R17F-Y0.18KW,R17F-Y0.25KW,R17F-Y0.37KW,R17F-Y0.55KW,R17F-Y0.75KW,R17F-Y63M4,R17F-Y71M4,R17F-Y80M4,R17F-YEJ0.12KW,R17F-YEJ0.18KW,R17F-YEJ0.25KW,R17F-YEJ0.37KW,R17F-YEJ0.55KW,R17F-YEJ0.75KW,R17F-YEJ63M4,R17F-YEJ71M4,R17F-YEJ80M4,R17F-YVP0.12KW,R17F-YVP0.18KW,R17F-YVP0.25KW,R17F-YVP0.37KW,R17F-YVP0.55KW,R17F-YVP0.75KW,R17F-YVP63M4,R17F-YVP71M4,R17F-YVP80M4,R17F-YVPEJ0.12KW,R17F-YVPEJ0.18KW,R17F-YVPEJ0.25KW,R17F-YVPEJ0.37KW,R17F-YVPEJ0.55KW,R17F-YVPEJ0.75KW,R17F-YVPEJ63M4,R17F-YVPEJ71M4,R17F-YVPEJ80M4。
R17系列減速機參數大全：同軸斜齒輪減速電機
R17F減速機配0.12KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.12KW | 81.64 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 70.39 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 65.61 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 57.35 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 53.76 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 47.44 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 44.18 | 0.12KW | 9.5kg | 2500N |
| R17F-Y0.12KW | 38.61 | 0.12KW | 9.5kg | 2430N |
| R17F-Y0.12KW | 36.20 | 0.12KW | 9.5kg | 2390N |
| R17F-Y0.12KW | 31.94 | 0.12KW | 9.5kg | 2310N |
| R17F-Y0.12KW | 28.32 | 0.12KW | 9.5kg | 2230N |
| R17F-Y0.12KW | 24.07 | 0.12KW | 9.5kg | 2130N |
R17F減速機配0.18KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.18KW | 81.64 | 0.18KW | 10kg | 47N |
| R17F-Y0.18KW | 70.39 | 0.18KW | 10kg | 1330N |
| R17F-Y0.18KW | 65.61 | 0.18KW | 10kg | 1740N |
| R17F-Y0.18KW | 57.35 | 0.18KW | 10kg | 2350N |
| R17F-Y0.18KW | 53.76 | 0.18KW | 10kg | 2500N |
| R17F-Y0.18KW | 47.44 | 0.18KW | 10kg | 2450N |
| R17F-Y0.18KW | 44.18 | 0.18KW | 10kg | 2410N |
| R17F-Y0.18KW | 38.61 | 0.18KW | 10kg | 2340N |
| R17F-Y0.18KW | 36.20 | 0.18KW | 10kg | 2300N |
| R17F-Y0.18KW | 31.94 | 0.18KW | 10kg | 2240N |
| R17F-Y0.18KW | 28.32 | 0.18KW | 10kg | 2170N |
| R17F-Y0.18KW | 24.07 | 0.18KW | 10kg | 2080N |
| R17F-Y0.18KW | 25.23 | 0.18KW | 10kg | 2110N |
| R17F-Y0.18KW | 23.15 | 0.18KW | 10kg | 2060N |
| R17F-Y0.18KW | 19.71 | 0.18KW | 10kg | 1970N |
| R17F-Y0.18KW | 16.99 | 0.18KW | 10kg | 1890N |
R17F減速機配0.25KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.25KW | 57.35 | 0.25KW | 14kg | 156N |
| R17F-Y0.25KW | 53.76 | 0.25KW | 14kg | 785N |
| R17F-Y0.25KW | 47.44 | 0.25KW | 14kg | 1630N |
| R17F-Y0.25KW | 44.18 | 0.25KW | 14kg | 2000N |
| R17F-Y0.25KW | 38.61 | 0.25KW | 14kg | 2200N |
| R17F-Y0.25KW | 36.20 | 0.25KW | 14kg | 2180N |
| R17F-Y0.25KW | 31.94 | 0.25KW | 14kg | 2120N |
| R17F-Y0.25KW | 28.32 | 0.25KW | 14kg | 2070N |
| R17F-Y0.25KW | 24.07 | 0.25KW | 14kg | 2000N |
| R17F-Y0.25KW | 25.23 | 0.25KW | 14kg | 2020N |
| R17F-Y0.25KW | 23.15 | 0.25KW | 14kg | 1980N |
| R17F-Y0.25KW | 19.71 | 0.25KW | 14kg | 1910N |
| R17F-Y0.25KW | 16.99 | 0.25KW | 14kg | 1840N |
| R17F-Y0.25KW | 15.84 | 0.25KW | 14kg | 1810N |
| R17F-Y0.25KW | 13.84 | 0.25KW | 14kg | 1740N |
| R17F-Y0.25KW | 12.98 | 0.25KW | 14kg | 1720N |
| R17F-Y0.25KW | 11.45 | 0.25KW | 14kg | 1660N |
R17F減速機配0.37KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.37KW | 38.61 | 0.37KW | 14.5kg | 770N |
| R17F-Y0.37KW | 36.20 | 0.37KW | 14.5kg | 1260N |
| R17F-Y0.37KW | 31.94 | 0.37KW | 14.5kg | 1910N |
| R17F-Y0.37KW | 28.32 | 0.37KW | 14.5kg | 1880N |
| R17F-Y0.37KW | 24.07 | 0.37KW | 14.5kg | 1830N |
| R17F-Y0.37KW | 25.23 | 0.37KW | 14.5kg | 1840N |
| R17F-Y0.37KW | 23.15 | 0.37KW | 14.5kg | 1820N |
| R17F-Y0.37KW | 19.71 | 0.37KW | 14.5kg | 1760N |
| R17F-Y0.37KW | 16.99 | 0.37KW | 14.5kg | 1710N |
| R17F-Y0.37KW | 15.84 | 0.37KW | 14.5kg | 1680N |
| R17F-Y0.37KW | 13.84 | 0.37KW | 14.5kg | 1630N |
| R17F-Y0.37KW | 12.98 | 0.37KW | 14.5kg | 1610N |
| R17F-Y0.37KW | 11.45 | 0.37KW | 14.5kg | 1560N |
| R17F-Y0.37KW | 10.15 | 0.37KW | 14.5kg | 1520N |
| R17F-Y0.37KW | 8.63 | 0.37KW | 14.5kg | 1460N |
| R17F-Y0.37KW | 7.55 | 0.37KW | 14.5kg | 1370N |
| R17F-Y0.37KW | 7.04 | 0.37KW | 14.5kg | 1350N |
| R17F-Y0.37KW | 6.15 | 0.37KW | 14.5kg | 1300N |
| R17F-Y0.37KW | 5.76 | 0.37KW | 14.5kg | 1280N |
| R17F-Y0.37KW | 5.09 | 0.37KW | 14.5kg | 1240N |
| R17F-Y0.37KW | 4.51 | 0.37KW | 14.5kg | 1200N |
| R17F-Y0.37KW | 3.83 | 0.37KW | 14.5kg | 1140N |
R17F減速機配0.55KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.55KW | 19.71 | 0.55KW | 19kg | 1580N |
| R17F-Y0.55KW | 16.99 | 0.55KW | 19kg | 1560N |
| R17F-Y0.55KW | 15.84 | 0.55KW | 19kg | 1540N |
| R17F-Y0.55KW | 13.84 | 0.55KW | 19kg | 1510N |
| R17F-Y0.55KW | 12.98 | 0.55KW | 19kg | 1490N |
| R17F-Y0.55KW | 11.45 | 0.55KW | 19kg | 1460N |
| R17F-Y0.55KW | 10.15 | 0.55KW | 19kg | 1430N |
| R17F-Y0.55KW | 8.63 | 0.55KW | 19kg | 1380N |
| R17F-Y0.55KW | 7.55 | 0.55KW | 19kg | 1290N |
| R17F-Y0.55KW | 7.04 | 0.55KW | 19kg | 1270N |
| R17F-Y0.55KW | 6.15 | 0.55KW | 19kg | 1230N |
| R17F-Y0.55KW | 5.76 | 0.55KW | 19kg | 1220N |
| R17F-Y0.55KW | 5.09 | 0.55KW | 19kg | 1180N |
| R17F-Y0.55KW | 4.51 | 0.55KW | 19kg | 1150N |
| R17F-Y0.55KW | 3.83 | 0.55KW | 19kg | 1100N |
R17F減速機配0.75KW電機參數
| 型號 | 減速比 | 功率 | 重量 | 力矩 |
| R17F-Y0.75KW | 19.71 | 0.75KW | 20kg | 820N |
| R17F-Y0.75KW | 16.99 | 0.75KW | 20kg | 1390N |
| R17F-Y0.75KW | 15.84 | 0.75KW | 20kg | 1380N |
| R17F-Y0.75KW | 13.84 | 0.75KW | 20kg | 1370N |
| R17F-Y0.75KW | 12.98 | 0.75KW | 20kg | 1360N |
| R17F-Y0.75KW | 11.45 | 0.75KW | 20kg | 1340N |
| R17F-Y0.75KW | 10.15 | 0.75KW | 20kg | 1320N |
| R17F-Y0.75KW | 8.63 | 0.75KW | 20kg | 1280N |
| R17F-Y0.75KW | 7.55 | 0.75KW | 20kg | 1190N |
| R17F-Y0.75KW | 7.04 | 0.75KW | 20kg | 1180N |
| R17F-Y0.75KW | 6.15 | 0.75KW | 20kg | 1150N |
| R17F-Y0.75KW | 5.76 | 0.75KW | 20kg | 1140N |
| R17F-Y0.75KW | 5.09 | 0.75KW | 20kg | 1110N |
| R17F-Y0.75KW | 4.51 | 0.75KW | 20kg | 1080N |
| R17F-Y0.75KW | 3.83 | 0.75KW | 20kg | 1040N |
R18減速機生產工廠展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約
推薦類似型號：R168減速機
關鍵詞:同向減速機臥式配電機一體式_R系列減速電機_R系列減速機_R系列減速器_同向減速器_GR型減速機_R向減速機_R系列斜齒輪減速機_GR系列減速機_R型減速機_GR系列斜齒輪減速機
R系列減速機型號：R18減速機,R28減速機,R38減速機,R48減速機,R58減速機,R68減速機,R78減速機,R88減速機,R98減速機,R108減速機,R138減速機,R148減速機,R168減速機
R系列齒輪減速馬達可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-132KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: R18減速機 R17臥式硬齒面斜齒輪減速機 R17系列減速機 R17減速機傳動比 R17減速機選型參數 R17減速機CAD三維圖
